Pixel Node 1 — Four-Way Modular Pixel
OverviewAn independently addressable RGB pixel with four-way connectivity for rapid prototyping of custom lighting geometries.
Key Features- Independent pixel control: program color, brightness, and dynamic effects separately.
- Four-way modular expansion: connect modules vertically or horizontally to create irregular structures.
- Selectable connection pads: bridge only the directions required by the layout.
- Cascadable architecture: combine Pixel Nodes into lines, graphics, text, and irregular arrays.
- Compact modular design: ideal for prototyping, DIY, robotics, wearables, and interactive installations.
- Unified development ecosystem: uses the same control logic as Pixel Bar, Pixel Ring, and Pixel Matrix.
- RGB and RGBW versions available with WS2812-series compatible control timing.
- Standard 1.27 mm 3-pin header layout for easy debugging and expansion.
Applications
Prototyping, electronics education, maker projects, and interactive installations.
Package, appearance, and internal model may vary by batch. Interface and control timing remain compatible.
